Laser Marking Machine – The Ultimate Solution for Permanent Marking

A laser marking machine is an advanced tool designed for high-precision, permanent marking on various materials, including metals, plastics, ceramics, and more. This technology ensures durable, high-contrast markings without causing damage to the material surface.

Unlike traditional marking methods, a laser marking machine provides non-contact, fast, and eco-friendly marking solutions. It is widely used in industries such as automotive, medical, aerospace, and electronics for engraving serial numbers, barcodes, logos, and other essential markings.

How Does a Laser Marking Machine Work?

A laser marking machine uses a focused laser beam to alter the surface properties of a material. The marking process involves:

Absorption of Laser Energy: The material absorbs the laser energy, causing localized changes.
Surface Alteration: The heat modifies the surface, creating high-contrast marks.
Cooling & Solidification: The marked area cools rapidly, ensuring precise and durable markings.

This advanced process ensures high-speed and detailed engraving without material wear and tear.

Specifications

Feature	CLS 20	CLS 30	CLS 50
Laser Power	20W	30W	50W
Laser Wavelength	1064 nm	1064 nm	1064 nm
Laser Frequency	20kHz - 80kHz	20kHz - 80kHz	20kHz - 80kHz
Maximum Linear Speed	7000 mm/s	7000 mm/s	7000 mm/s
Marking Size	70x70mm, 110x110mm, 175x175mm, 200x200mm, 300x300mm	70x70mm, 110x110mm, 175x175mm, 200x200mm, 300x300mm	70x70mm, 110x110mm, 175x175mm, 200x200mm, 300x300mm
Mini Font Height	0.2 mm	0.2 mm	0.2 mm
Minimum Line Width	0.01 mm	0.01 mm	0.01 mm
Repetition Accuracy	±0.003 mm	±0.003 mm	±0.003 mm
Operating Power	0.5KW/AC220V/50Hz	0.5KW/AC220V/50Hz	0.5KW/AC220V/50Hz
File Format Support	AI, PLT, PCX, DXF, BMP	AI, PLT, PCX, DXF, BMP	AI, PLT, PCX, DXF, BMP
2D Matrix, Linear Barcode	Yes	Yes	Yes
Work Environments	10-40°C, Humidity: 10%-90%	10-40°C, Humidity: 10%-90%	10-40°C, Humidity: 10%-90%
Cooling Type	Air Cooled	Air Cooled	Air Cooled
